Practice With Box And Whisker Plots

Box and whisker plots, also known as box plots, are powerful visual tools for displaying the distribution of a dataset. Consider this: mastering their creation and interpretation unlocks a deeper understanding of data's central tendency, spread, and potential outliers. This article breaks down the practical aspects of working with box and whisker plots, providing examples and exercises to solidify your understanding.

Understanding the Anatomy of a Box and Whisker Plot

Before diving into practice problems, let's quickly recap the key components of a box and whisker plot:

• The Box: Represents the interquartile range (IQR), containing the middle 50% of the data. The left edge of the box is the first quartile (Q1), the right edge is the third quartile (Q3), and a line inside the box marks the median (Q2).
• Whiskers: Extend from each end of the box to the furthest data point within a defined range. Typically, this range is 1.5 times the IQR from each quartile.
• Outliers: Data points that fall outside the whiskers are considered outliers and are plotted individually as dots or asterisks.

Understanding these components is crucial for accurately interpreting the information presented in a box and whisker plot.

Constructing Box and Whisker Plots: A Step-by-Step Guide

Creating a box and whisker plot involves several steps. Let's illustrate this process with an example:

Example Data: The following data represents the test scores of 15 students: 65, 70, 72, 75, 78, 80, 82, 85, 85, 88, 90, 92, 94, 95, 98

Step 1: Order the Data

Arrange the data in ascending order. This is already done in our example.

Step 2: Calculate the Median (Q2)

The median is the middle value. With 15 data points, the median is the 8th value, which is 85.

Step 3: Calculate the First Quartile (Q1)

Q1 is the median of the lower half of the data (excluding the median if the dataset has an odd number of data points). The lower half is: 65, 70, 72, 75, 78, 80, 82. The median of this set is 75.

Step 4: Calculate the Third Quartile (Q3)

Q3 is the median of the upper half of the data (excluding the median if the dataset has an odd number of data points). The upper half is: 88, 90, 92, 94, 95, 98. The median of this set is (92+94)/2 = 93.

Step 5: Calculate the Interquartile Range (IQR)

IQR = Q3 - Q1 = 93 - 75 = 18

Step 6: Determine the Upper and Lower Bounds for Whiskers

• Upper Bound: Q3 + 1.5 * IQR = 93 + 1.5 * 18 = 93 + 27 = 120
• Lower Bound: Q1 - 1.5 * IQR = 75 - 1.5 * 18 = 75 - 27 = 48

Step 7: Identify Outliers

Any data points outside the upper and lower bounds are outliers. In this case, all data points are within the bounds, so there are no outliers.

Step 8: Determine Whisker Extents

The upper whisker extends to the highest data point that is not an outlier and is within the upper bound. And in this case, it extends to 98. Think about it: the lower whisker extends to the lowest data point that is not an outlier and is within the lower bound. In this case, it extends to 65.

Step 9: Draw the Box and Whisker Plot

• Draw a number line that covers the range of your data (e.g., from 60 to 100).
• Draw a box from Q1 (75) to Q3 (93).
• Draw a line inside the box at the median (85).
• Draw whiskers extending from the box to the furthest data points within the bounds (65 and 98).
• Mark any outliers (there are none in this example).

Practice Problems: Applying Your Knowledge

Now, let's test your understanding with some practice problems.

Problem 1:

Given the following dataset representing the number of hours students spend studying per week: 10, 12, 15, 18, 20, 22, 25, 28, 30, 35, 40

Construct a box and whisker plot for this data. Identify Q1, Q2 (median), Q3, IQR, upper bound, lower bound, and any outliers.

Solution to Problem 1:

1. Ordered Data: Already ordered.
2. Q2 (Median): 22
3. Q1: 15
4. Q3: 30
5. IQR: 30 - 15 = 15
6. Upper Bound: 30 + 1.5 * 15 = 52.5
7. Lower Bound: 15 - 1.5 * 15 = -7.5
8. Outliers: None (all data points are within the bounds)
9. Whisker Extents: Lower whisker extends to 10. Upper whisker extends to 40.

Problem 2:

The following data represents the heights (in inches) of basketball players: 68, 70, 72, 73, 75, 76, 76, 77, 78, 79, 80, 82, 83, 85, 90

Construct a box and whisker plot for this data. Identify Q1, Q2 (median), Q3, IQR, upper bound, lower bound, and any outliers.

Solution to Problem 2:

1. Ordered Data: Already ordered.
2. Q2 (Median): 77.5 ((77+78)/2)
3. Q1: 73
4. Q3: 82
5. IQR: 82 - 73 = 9
6. Upper Bound: 82 + 1.5 * 9 = 95.5
7. Lower Bound: 73 - 1.5 * 9 = 59.5
8. Outliers: None (all data points are within the bounds)
9. Whisker Extents: Lower whisker extends to 68. Upper whisker extends to 90.

Problem 3:

The following data represents the number of books read by members of a book club in a year: 5, 7, 8, 10, 12, 15, 15, 18, 20, 22, 25, 30, 35, 40, 60

Construct a box and whisker plot for this data. Identify Q1, Q2 (median), Q3, IQR, upper bound, lower bound, and any outliers.

Solution to Problem 3:

1. Ordered Data: Already ordered.
2. Q2 (Median): 18
3. Q1: 10
4. Q3: 30
5. IQR: 30 - 10 = 20
6. Upper Bound: 30 + 1.5 * 20 = 60
7. Lower Bound: 10 - 1.5 * 20 = -20
8. Outliers: None (The data point 60 falls on the upper bound, so it's not an outlier. If it were 61, it would be an outlier)
9. Whisker Extents: Lower whisker extends to 5. Upper whisker extends to 60.

Problem 4:

For more on this topic, read our article on words that describe the beach or check out you son't have to have it poerfect at the start.

The following data represents the waiting times (in minutes) at a doctor's office: 5, 8, 10, 12, 15, 20, 25, 30, 35, 40, 45, 50, 60, 75, 90

Construct a box and whisker plot for this data. Identify Q1, Q2 (median), Q3, IQR, upper bound, lower bound, and any outliers.

Solution to Problem 4:

1. Ordered Data: Already ordered.
2. Q2 (Median): 30
3. Q1: 12
4. Q3: 50
5. IQR: 50 - 12 = 38
6. Upper Bound: 50 + 1.5 * 38 = 107
7. Lower Bound: 12 - 1.5 * 38 = -45
8. Outliers: None (all data points are within the bounds)
9. Whisker Extents: Lower whisker extends to 5. Upper whisker extends to 90.

Problem 5:

The following dataset represents the number of customers visiting a store each day for two weeks: 25, 30, 32, 35, 38, 40, 42, 45, 48, 50, 52, 55, 60, 100

Construct a box and whisker plot for this data. Identify Q1, Q2 (median), Q3, IQR, upper bound, lower bound, and any outliers.

Solution to Problem 5:

1. Ordered Data: Already ordered.
2. Q2 (Median): 43.5 ( (42+45)/2 )
3. Q1: 35
4. Q3: 52
5. IQR: 52 - 35 = 17
6. Upper Bound: 52 + 1.5 * 17 = 77.5
7. Lower Bound: 35 - 1.5 * 17 = 9.5
8. Outliers: 100
9. Whisker Extents: Lower whisker extends to 25. Upper whisker extends to 60.

Interpreting Box and Whisker Plots: Drawing Meaning from the Visual

Creating a box and whisker plot is only half the battle. The real power lies in interpreting the plot to gain insights into the data. Here are some key interpretations:

• Central Tendency: The median line within the box provides a quick visual of the dataset's central tendency. Compare the median locations across multiple box plots to quickly compare the typical values of different datasets.
• Spread/Variability: The length of the box (IQR) indicates the spread of the middle 50% of the data. A longer box signifies greater variability. The overall range (distance between the extreme whisker points) shows the total spread of the data, excluding outliers.
• Skewness: The position of the median within the box, and the relative lengths of the whiskers, can indicate skewness.
  • Symmetrical Distribution: If the median is in the center of the box and the whiskers are roughly equal in length, the distribution is approximately symmetrical.
  • Right Skew (Positive Skew): If the median is closer to the bottom of the box, and/or the right whisker is significantly longer than the left whisker, the distribution is skewed to the right. This means there are some high values pulling the mean upwards, away from the median.
  • Left Skew (Negative Skew): If the median is closer to the top of the box, and/or the left whisker is significantly longer than the right whisker, the distribution is skewed to the left. This means there are some low values pulling the mean downwards, away from the median.
• Outliers: The presence of outliers can highlight unusual or extreme values in the dataset that warrant further investigation. These could be errors in data collection, or they could represent genuinely interesting anomalies.
• Comparing Distributions: Box and whisker plots are excellent for comparing the distributions of different datasets. By placing multiple box plots side-by-side, you can easily compare their medians, spreads, and skewness.

Advanced Applications and Considerations

While the basic principles remain the same, box and whisker plots can be adapted and used in more advanced scenarios.

• Variable Width Box Plots: In a variable width box plot, the width of the box is proportional to the square root of the number of data points in that group. This provides a visual indication of the sample size for each group being compared. Wider boxes indicate larger sample sizes, lending more credence to the statistics derived from those groups.
• Notched Box Plots: Notched box plots add a "notch" around the median. The extent of the notch represents a confidence interval (typically 95%) for the median. If the notches of two box plots do not overlap, this suggests a statistically significant difference between the medians of the two groups.
• Box Plots with Grouped Data: Box plots can be used to visualize the distribution of data for different groups within a dataset. Take this: you could create box plots of test scores for different classes, or the sales performance of different regions.
• Software for Creating Box Plots: While you can create box plots manually, statistical software packages like R, Python (with libraries like Matplotlib and Seaborn), SPSS, and Excel offer convenient tools for generating box plots with various customization options.

Common Mistakes to Avoid

• Misinterpreting Whiskers: Remember that whiskers extend to the furthest data point within the calculated bounds, not necessarily to the maximum and minimum values in the dataset.
• Ignoring Outliers: Don't simply discard outliers without investigating them. They can provide valuable insights.
• Using Box Plots for Small Datasets: Box plots are most effective with datasets that have a reasonable number of data points (generally, at least 10-15). With very small datasets, the box plot may not accurately represent the distribution.
• Confusing Box Plots with Histograms: While both display data distribution, box plots point out quartiles and outliers, while histograms show the frequency of data within specific intervals.

The Power of Visualization

Box and whisker plots are more than just pretty pictures; they are powerful tools for data exploration and communication. They provide a concise and informative way to summarize and compare datasets, highlight potential outliers, and gain insights into the distribution of data. By mastering the art of creating and interpreting box and whisker plots, you'll be well-equipped to analyze data and make informed decisions.

Conclusion

Practice is key to mastering box and whisker plots. That's why as you gain experience, you'll develop a strong intuition for interpreting these plots and extracting valuable insights from your data. Even so, box and whisker plots provide a valuable and accessible way to visualize and understand data distributions, empowering you to make informed decisions based on evidence. Work through the examples provided, create your own datasets, and experiment with different variations of box plots. Embrace the power of visualization and tap into the secrets hidden within your data!
