Introduction

When analyzing a simply supported beam subjected to various loading conditions, engineers often assume that the flexural rigidity EI—the product of the material’s Young’s modulus (E) and the beam’s second moment of area (I)—remains constant along its length. In the context of Figure 1, this assumption simplifies the mathematical modeling while still capturing the essential behavior of the structure. This article explains why EI is taken as constant, walks through the step‑by‑step procedure for determining internal forces and deflections, and addresses common questions that arise during practical design.

Why Assume a Constant EI?

1. Material Homogeneity – If the beam is made from a single, isotropic material, E does not vary with position. 2. Geometric Uniformity – A prismatic beam (constant cross‑section) ensures that I stays the same along the span.
2. Simplified Calculations – Keeping EI constant allows the use of standard formulas for bending, shear, and deflection without piecewise integration.

When either material composition or cross‑section changes, engineers must resort to a variable EI approach, but for most textbook problems and many real‑world designs, the constant‑EI model is sufficiently accurate.

Problem Statement

Figure 1 depicts a simply supported beam of length L with a uniform distributed load w (N/m) applied across the entire span. The beam’s flexural rigidity EI is assumed to be constant. The objectives are to:

• Determine the bending moment diagram.
• Construct the shear force diagram.
• Compute the deflection curve of the beam.

These results provide insight into the beam’s structural performance under the given loading.

Step‑by‑Step Solution

1. Support Reactions

For a simply supported beam with uniform load w, the reactions at the left (R₁) and right (R₂) supports are equal:

[ R_1 = R_2 = \frac{wL}{2} ]

Key takeaway: The symmetry of the loading simplifies reaction calculations.

2. Shear Force Equation

The shear force V(x) at a distance x from the left support is:

[V(x) = R_1 - wx = \frac{wL}{2} - wx]

• At x = 0, (V = \frac{wL}{2}).
• At x = L, (V = -\frac{wL}{2}). The shear line is linear, decreasing from positive to negative values.

3. Bending Moment Equation

Integrating the shear equation yields the bending moment M(x):

[ M(x) = R_1 x - \frac{w x^2}{2} = \frac{wL}{2}x - \frac{w x^2}{2} ]

The bending moment diagram is a parabolic curve, reaching a maximum at the mid‑span (x = L/2):

[ M_{\max} = \frac{wL^2}{8} ]

4. Slope and Deflection

The differential equation governing the elastic curve of a beam is:

[ \frac{d^2 y}{dx^2} = \frac{M(x)}{EI} ]

Integrating twice and applying boundary conditions (y(0) = 0, y(L) = 0) provides the deflection y(x):

[ y(x) = \frac{w x (L^3 - 2L x^2 + x^3)}{24EI} ]

The maximum deflection occurs at the centre of the beam (x = L/2):

[ y_{\max} = \frac{5 w L^4}{384 EI} ]

Interpretation: Deflection is inversely proportional to EI; a stiffer beam (larger EI) deforms less.

Scientific Explanation of the Constant‑EI Model

• Young’s Modulus (E) quantifies material stiffness; for steel, concrete, or aluminum, it is essentially uniform along the length unless temperature gradients or phase changes are present.
• Second Moment of Area (I) depends solely on geometry. For a prismatic rectangular section of width b and height h, (I = \frac{b h^3}{12}). Since b and h do not change, I stays constant.

So naturally, the product EI remains unchanged, justifying its treatment as a single constant in analytical formulas. This constancy enables the superposition principle to be applied, allowing linear combinations of loads to be analyzed separately and then summed.

Example Calculation

Assume a steel beam with the following properties:

• Length L = 6 m
• Uniform load w = 10 kN/m
• Modulus E = 210 GPa
• Cross‑section: 0.2 m × 0.4 m → (I = \frac{0.2 \times 0.4^3}{12} = 0.001067 m^4)

Compute EI:
